Product Description
Description: 1.Our Rubber Strip Cutting Machine (Rubber Strip Cutter )is optimized in structure and easy to operate.With glass plates positioning in front make the operation more secure. Feeding platform is made of pure mirror stainless steel, truly beautiful appearance and guarantees safe production, high automation, easy operation and low noise and has a good safety device, automatic lift feed roller device is also a friendly design. 2.The blade of the machine is alloy inlaid high speed wear-resistant material, sharp and long life service. 3. Rubber Strip Cutting Machine is controlled by PLC and stepper motor,with mechanical-spring material press roller to make the rubber sheet feeding more accurate and smooth,improving the cut precision for the rubber strip.Easy operation, operator just input the desired width in the computer,the right width strip will be cut continuously.During cutting process, you can freely adjust the width of cut material as per your actual need.This CNC type Rubber Strip Cutting Machine,combining advanced CNC automatic mechanical and electric integration system,it overcome the problem for the normal strip cutting machine whose transmission parts could be wearing after long time use. 4.Automatic Rubber Strip/Blank Cutting Machine with electronic scale for cutting weight control is available for option.
Auto Electronic-scale type Rubber Strip Cutter: Input the cutting weight on the touch screen, and the electronic scale will automatically calibrate the cutting width and feedback to PLC,then the desired weight will be cut.
Technical Specification: | Model | XQ-450 | XQ-600 | XQ-800 | XQ-1000 | XQ-1200 |
| Max. feeding rubber width(mm) | 450 | 620 | 820 | 1000 | 1220 |
Max. cutting thickness
(mm) | 20 | 20 | 20 | 20 | 20 |
Max.
Cut efficiency
(times/min) | 86 | 86 | 80 | 80 | 65 |
| Cut precision | ±0.1mm | ±0.1mm | ±0.1mm | ±0.1mm | ±0.1mm |
| Motor power(KW) | 1.5 | 1.5 | 2.5/3 | 2.5/3 | 4/5.5 |
Dimension
(LxWxH:cm) | 105x70x110 | 115x85x110 | 140x96x120 | 165x100x123 | 180x100x142 |
| Weight(Kg) | 500 | 750 | 840 | 1050 | 1200 |
Notes: the form only list out the normal standard model, more special models can be customized to order. Packaging & Shipping
The rubber strip cutting machines are packaged well by the strong wooden case,ensuring the machines non damage during the long distance of land and sea transportation, and reach the clients factories safely.
After Sales Service
We supply quick after sales service, including online consultation,instruction and also onsite face-face service if required by the clients.
We have professtional after sales serivce team who can give you satisfactory quick response,including technical questions,trouble-shooting,installation,etc.
Our business principle is that :
Move ahead along with the spirit of "Responsibility& Sincerity for Customers" and "Cooperative&Enterprising Team" to "Create a Better Future Together ".
It is our promise and duty to execute the 3 No worries for clients:
No worries before order,
No worries after order,
No worries in produciton.
